LabQuest® 3

LabQuest 3 is a powerful, advanced, easy-to-navigate, and versatile data-logging solution for STEM students.

SKU: LABQ3 Category:

$535.00

The all-new LabQuest 3 is a standalone data-collection platform that students can use to collect, analyze, and interact with data efficiently. With its new capacitive touch screen, students can navigate the platform with ease, and because of its wireless capabilities, students can collect data anywhere with LabQuest 3.

Connects wirelessly to the entire family of Go Direct® sensors
Easy-to-use platform enables students to generate graphs and analyze results
An excellent choice for laboratories, classrooms, or in-the-field investigations

Key Features

  • Full-featured data-collection platform
  • Compatible with all Vernier sensors
  • Large, high-resolution color screen
  • Touch navigation utilizing gestures
  • Fast data collection with 100,000 samples per second
  • Rechargeable, high-capacity battery
  • Built-in GPS and microphone
  • Wireless connectivity with Wi-Fi and Bluetooth® wireless technology
  • Built-in apps include Calculator, Periodic Table, Sound Recorder, Stopwatch, and more
  • Student instructions for over 75 of our most popular experiments included

Connectivity to Chromebooks, Computers, iPad® tablets, and Mobile Devices

Students can share real-time data with multiple devices for a truly hands-on, collaborative learning experience. Use LabQuest 3 to transfer data wirelessly to computers, Chromebooks, or mobile devices running Graphical Analysis™ 4.

USB Sensor Interface

If you want to use your own computer or Chromebook™ to collect data, use LabQuest 3 as a conduit between our LabQuest sensors and these devices. LabQuest 3 works as a USB sensor interface with our Logger Pro® software or Graphical Analysis 4 app.

Specifications

Display

  • 15.41 cm x 8.59 cm (17.64 cm diagonal) screen
  • LED backlight
  • Landscape screen orientation

Processor

  • 2 GHz Application Processor

Connectivity

  • Wi-Fi 802.11 b/g/n @ 2.4GHz
  • Bluetooth® wireless technology

Touch Interface

  • Capacitive touch screen
  • Touch navigation utilizing gestures, including the following. For a full list, see the user manual.
    • Single tap—Use a single tap to interact with most objects on the device.
    • Touch and drag—Use touch and drag to select regions on a graph or to scroll through menus.
    • Long Press—Use the long press to activate special functionality on some objects such as holding down the keyboard shift key to enable shift lock, or to initial a table selection.
    • Two-Finger Pinch/Zoom/Pan—Use this gesture to manually scale graphs or pan the data table.
    • Double tap—Double tap to scale the graph to fit the data or to edit elements of the data table such as cell data (when allowed), column name, or dataset name.
    • Single-finger swipe (from edges)—This gesture is used to change what app is displayed.

Data Acquisition

  • 100,000 samples per second
  • 12-bit resolution
  • Built-in GPS and microphone

Environmental Durability

  • Operating temperature: 0 – 45°C
  • Storage temperature: -30 – 60°C
  • Splash resistant
  • Rugged enclosure designed to withstand a fall from lab bench

Size and Weight

  • Size: 11.7 cm x 19.0 cm x 4.0 cm
  • Weight: 549 g

Ports

  • 3 analog ports
  • 2 digital ports
  • 2 full-size USB ports for sensors
  • Micro USB port for computer communication
  • Audio out
  • DC power port

Storage

  • 500 MB
  • Expandable with USB flash drive

Power

  • Rechargeable, high-capacity battery
  • DC charging/powering through external adapter (included)

What's Included

  • Vernier LabQuest 3 interface
  • Micro USB Cable
  • AC power adapter
  • Quick-Start Guide

Software

Analysis Features

  • Perform linear and curve fits
  • Draw a prediction before collecting data
  • Display two graphs at once
  • Display a tangent line on the graph
  • Display integral functions
  • Analyze statistics
  • Perform FFT analysis

Built-In Applications

  • Stopwatch
  • Periodic Table
  • Sound Recorder (for voice annotation)
  • Scientific Calculator
  • Audio Function Generator
  • Power Amplifier (requires Vernier Power Amplifier)

Versatile Tools and Resources

  • More than 75 preloaded lab instructions from our popular lab books
  • Notes field
  • Email screenshots and data files for use in lab reports or submit directly to an instructor
  • Export data to Logger Pro, Excel®, and other data analysis software
  • Stream data wirelessly to computers, Chromebooks, and mobile devices running our Graphical Analysis 4 app.

USB Interface Compatibility

You can also use LabQuest 3 as a computer interface using the Graphical Analysis 4 app or Logger Pro 3 software.

Graphical Analysis 4 App for Computers and Chromebooks

Collect and analyze sensor ‭data with our free Graphical Analysis 4 app ‭for Chrome‭‭, ‭Windows®, macOS®‭, iOS‭®‭, and Android‭‭. Use LabQuest 2 as a USB sensor interface on a computer or Chromebook.

Learn more about Graphical Analysis 4

Logger Pro 3 Software for Computers

Our award-winning Logger Pro 3 software provides advanced analytical features including video analysis. One copy of Logger Pro includes a site license for all computers in your school or your college department, as well as students’ personal computers.

Learn more about Logger Pro 3

Support

Resources

Warranty

5-year limited warranty (1 year on battery)
See our warranty policy
